AFPX-IN8 Panasonic PANASONIC Input Plugin
FP-X functional plugin products and their specifications:
Input/output plug-in AFPX-IN4T3: Input 4 points, 24V DC, bidirectional output 3 points, NPN transistor 0.3A/24V DC
Input plug-in AFPX-IN8: Input 8 points, 24V DC, bidirectional
Output plug-in AFPX-TR8: Output 8 points, NPN transistor 0.3A/24V DC
Output plug-in AFPX-TR6P: Output 6 points, PNP transistor 0.5A/24V DC
Pulse input/output plug-in AFPX-PLS: high-speed counter: single-phase 2ch, each 80kHz, or two-phase 1ch, 30kHz
Pulse output: 1-axis 100kHz/ch (with specification limitations when installing 2 units)
Transistor output control unit not available
Analog input plug-in AFPX-AD2: Analog input 2 points, 0-10V or 0-20mA, 12 bits, 2ms/2ch (non insulated)
Analog output plug-in AFPX-DA2: Analog output 2 points, 0-10V or 0-20mA, 12 bits, 2ms/2ch (insulation)
Analog I/O plug-in AFPX-A21: Analog input 2 points, 0-5V, 0-10V or 0-20mA, 12 bits, 2ms/2ch
Analog output 1 point, 0-10V or 0-20mA, 12 bits, 1ms/1ch (insulation)
Thermocouple plug-in AFPX-TC2: thermocouple input 2 points, K/J, resolution 0.2 ℃, 200ms/2ch (channel to channel insulation)
Thermal resistor plug-in AFPX-RTD2: Thermal resistor input 2 points, resolution 0.1 ℃, channel to channel insulation type
Real time clock based main memory AFPX-MRTC:
Main memory: can simultaneously save the entire sequence and all annotations; FPWIN Pro source file can be saved
Calendar clock: year, month, day, hour, minute, second, week (requires battery option)
