HART Multiplexer Master KFD2-HMM-16
  1. HART Multiplexer Master KFD2-HMM-16

HART Multiplexer Master KFD2-HMM-16

Product Item:KFD2-HMM-16

KFD2-HMM-16
Send Inquiry Live chat

Description

Product Description
HART Multiplexer Master
Functional safety related parameters
Safety Integrity Level (SIL) SIL 3
Supply
Connection terminals 17+, 18-
Rated voltage 20 ... 32 V DC typical at 100 mA
Power consumption max. 3 W
HART signal channels (non-intrinsically safe)
Conformity HART field device input (revision 5 to 7)
Connection 26-pin flat cable for analog connections
14-pin flat cable for master-slave connection between KFD2-HMM-16 and KFD0-HMS-16
Leakage current < 3 µA at -20 ... 85 °C (-4 ... 185 °F)
Terminating resistor external 230 ... 500 Ω standard (up to 1000 Ω possible)
Output voltage ≥ 400 mV ss (with the terminator resistance specified above)
Output resistance 100 Ω or smaller, capacitive coupling
Input impedance according to HART specification
Input voltage range 0.08 ... 4 V ss ; typ. ± 5.2 V as local reference
Interface
Transfer rate 9600, 19200, or 38400 Bit/s (selectable with DIL switch (2 and 3) by the user)
Type RS-485 , 2-wire multidrop
Address selection One of 31 possible addresses selectable per DIL switch (4 ... 8)
Indicators/settings
Control elements DIP switch
Configuration via DIP switches
Labeling space for labeling at the front
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)
Conformity
Degree of protection IEC 60529:2001
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Mechanical specifications
Degree of protection IP20
Connection screw terminals
Mass approx. 250 g
Dimensions 40 x 107 x 115 mm (1.6 x 4.2 x 4.5 inch) (W x H x D) , housing type C1
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001
Data for application in connection with hazardous areas
Certificate PF 07 CERT 1143 X
Marking Ex-Hexagon II 3G Ex nA IIC T4 Gc
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-15:2010
General information
Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.

Classifications

System Classcode
ECLASS 11.0 27210190
ECLASS 10.0.1 27210190
ECLASS 9.0 27210190
ECLASS 8.0 27210190
ECLASS 5.1 27242692
ETIM 8.0 EC001601
ETIM 7.0 EC001601
ETIM 6.0 EC001601
ETIM 5.0 EC001597
UNSPSC 12.1 39121008
