Inductive sensor NBB4-12GM30-E2 PEPPERL FUCHS

Technical Data
General specifications
Switching function Normally open (NO)
Output type PNP
Rated operating distance sn 4 mm
Installation flush
Output polarity DC
Assured operating distance sa 0 ... 3.24 mm
Actuating element mild steel, e. g. 1.0037, SR235JR (formerly St37-2)
12 mm x 12 mm x 1 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.35
Reduction factor r304 0.79
Reduction factor rBrass 0.49
Output type 3-wire
Nominal ratings
Operating voltage UB 5 ... 36 V
Switching frequency f 0 ... 2550 Hz
