KFU8-VCR-1 Pepperl+Fuchs Transmitter Power Supply/Converter
  1. KFU8-VCR-1 Pepperl+Fuchs Transmitter Power Supply/Converter

KFU8-VCR-1 Pepperl+Fuchs Transmitter Power Supply/Converter

Product Item:KFU8-VCR-1

KFU8-VCR-1
Send Inquiry Live chat PDF

Description

General specifications
Signal type Analog input
Supply
Connection terminals 14, 15
Rated voltage 19 ... 90 V DC / 48 ... 253 V AC
Rated current ≤ 110 mA DC / ≤ 75 mA AC
Power dissipation 1.3 W
Power consumption 2.1 W
Input
Connection side field side
Input I
Connection terminals 1+, 2-, 3
Input signal 0/4 ... 20 mA
Rated current 22 mA
Available voltage > 15 V at 20 mA , terminals 1+, 3-
Open circuit voltage/short-circuit current 21 V / 26 mA , terminals 1+, 3-
terminals 1+, 2- not short-circuit protected
Input resistance < 55 Ω , terminals 2-, 3+
Input II
Connection terminals 5-, 6+
Input signal 0/2 ... 10 V
Input resistance > 1 MΩ
Output
Connection side control side
Output I current output
Connection source: terminals 7(-), 8(+)
sink: terminals 7(+), 9(-)
Output signal 0/4 ... 20 mA
Source load 0 ... 750 Ω open circuit voltage < 21 V
Sink voltage across terminals 5 ... 30 V
Output II voltage output
Connection terminals 10-, 11+
Output signal 0/2 ... 10 V
Load min. 10 kΩ
Transfer characteristics
Deviation
Resolution/accuracy S1 in position I: 7 µA/40 µA (0.2 %)
S1 in position II: 3.5 mV/20 mV (0.2 %)
Influence of ambient temperature 0.01 % / K of output signal range
Reaction time 150 ms
Galvanic isolation
Input/Output functional insulation acc. to IEC 62103, rated insulation voltage 100 Vrms
Input/power supply reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Output/power supply reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Indicators/settings
Display elements LED
Control elements DIP switch
rotary switch
Configuration via DIP switches
via rotary switch
Labeling space for labeling at the front
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)
Low voltage
Directive 2014/35/EU EN 61010-1:2010
Conformity
Electromagnetic compatibility NE 21:2006
Degree of protection IEC 60529:1989+A1:1999+A2:2013
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Mechanical specifications
Degree of protection IP20
Connection screw terminals
Mass approx. 150 g
Dimensions 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) (W x H x D) , housing type B2
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001
General information
Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.

Classifications

System Classcode
ECLASS 11.0 27210119
ECLASS 10.0.1 27210119
ECLASS 9.0 27210119
ECLASS 8.0 27210119
ECLASS 5.1 27210119
ETIM 8.0 EC001485
ETIM 7.0 EC001485
ETIM 6.0 EC001485
ETIM 5.0 EC001485
UNSPSC 12.1 32101514
