PEPPERL + FUCHS KHA6-SH-EX1 SWITCH AMPLIFIER 46904S
  1. PEPPERL + FUCHS KHA6-SH-EX1 SWITCH AMPLIFIER 46904S

PEPPERL + FUCHS KHA6-SH-EX1 SWITCH AMPLIFIER 46904S

KHA6-SH-EX1
Send Inquiry Live chat PDF

Description

General specifications
Signal type Digital Input
Functional safety related parameters
Safety Integrity Level (SIL) SIL 3
Performance level (PL) PL d
Supply
Connection terminals 22, 23, 24
Rated voltage 85 ... 253 V AC , 45 ... 65 Hz
Rated current 30 mA ± 5 mA
Power dissipation 2.2 W
Power consumption max. 2.3 W
Input
Connection side field side
Connection terminals 10+, 12-
Open circuit voltage/short-circuit current approx. 8.4 V DC / approx. 11.7 mA
Lead resistance ≤ 50 Ω, in hazardous area cable capacitances and inductivities are to be taken into account
Switching point
Relay de-energized I < 2.1 mA and I > 5.9 mA
Relay energized 2.8 mA < I < 5.3 mA
Response delay ≤ 1 ms
Output
Connection side control side
Connection output I: terminals 13, 14 ; output II: terminals 15, 21 ; output III: terminals 16+, 17-
Output I relay , signal
Contact loading 253 V AC/1 A/cos φ ≥ 0.7; 24 V DC/1 A resistive load
Mechanical life 50 x 106 switching cycles
Output II relay , signal
Contact loading 253 V AC/1 A/cos φ ≥ 0.7; 24 V DC/1 A resistive load
Mechanical life 50 x 106 switching cycles
Output III electronic output, passive , fault signal
Rated voltage 10 ... 30 V DC
Signal level 1-signal: (L+) -2.5 V (7 mA, short-circuit proof) / 0-signal: blocked output
(Leakage current ≤ 10 µA)
Transfer characteristics
Switching frequency 5 Hz
Indicators/settings
Display elements LEDs
Labeling space for labeling at the front
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)
Machinery Directive
Directive 2006/42/EC EN/ISO 13849-1:2015
Conformity
Electromagnetic compatibility NE 21:2011
Degree of protection IEC 60529:2001
Safety IEC/EN 61508:2010
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Mechanical specifications
Degree of protection IP20
Connection screw terminals
Mass approx. 280 g
Dimensions 40 x 93 x 115 mm (1.6 x 3.7 x 4.5 inch) (W x H x D) , housing type E
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001
Data for application in connection with hazardous areas
EU-type examination certificate PTB 00 ATEX 2043
Marking Ex-Hexagon II (1)G [Ex ia Ga] IIC
Ex-Hexagon II (1)D [Ex ia Da] IIIC
Ex-Hexagon I (M1) [Ex ia Ma] I
Input Ex ia
Voltage 9.56 V
Current 16.8 mA
Power 41 mW (linear characteristic)
Supply
Maximum safe voltage 253 V AC/DC (Attention! The rated voltage can be lower.)
Output
Contact loading 253 V AC/1 A/cos φ ≥ 0.7; 24 V DC/1 A resistive load
Maximum safe voltage output I/output II: 253 V AC/DC (Attention! Um is no rated voltage.)
Galvanic isolation
Input/Output safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Input/power supply safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Directive conformity
Directive 2014/34/EU EN IEC 60079-0:2018+AC:2020 , EN 60079-11:2012
General information
Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.

Classifications

System Classcode
ECLASS 11.0 27210121
ECLASS 10.0.1 27210121
ECLASS 9.0 27210121
ECLASS 8.0 27210121
ECLASS 5.1 27210121
ETIM 8.0 EC001485
ETIM 7.0 EC001485
ETIM 6.0 EC001485
ETIM 5.0 EC001485
UNSPSC 12.1 32101514
