Description
Technical Data
General specifications
Switching function Normally open/closed (NO/NC)
Output type Two-wire
Rated operating distance sn 20 mm
Installation flush
Output polarity AC/DC
Assured operating distance sa 0 ... 16.2 mm
Actual operating distance sr 18 ... 22 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.3
General specifications
Switching function Normally open/closed (NO/NC)
Output type Two-wire
Rated operating distance sn 20 mm
Installation flush
Output polarity AC/DC
Assured operating distance sa 0 ... 16.2 mm
Actual operating distance sr 18 ... 22 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.3
