Description
Physical size and weight
| Net weight | 1.38 kg |
|---|---|
| Operating pressure, max. | 350 bar |
| Max. flow | 25 l/min |
Other properties
| Connection diagram | ISO 4401-03-02-0-05 |
|---|---|
| ECLASS_13_Classification | 51-44-01-01 |
| Product family | M-.SED6 |
| Spool symbol | Symbol CK |
| Type of connection | Subplate mounting |
| Size | 6 |
| Type of actuation | with solenoid actuation |
| Number of ports | 3 |
| Number of switching positions | 2 |
| Supply voltage | 205 VDC |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Conformity | UKCA,CE |
| Conformity description | UKCA – Low-Voltage Directive SI2016/1091,CE – Low-Voltage Directive 2014/35/EU |
| Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD |
| Seals | NBR |
