Description
Physical size and weight
| Net weight | 2.26 kg |
|---|---|
| Operating pressure, max. | 350 bar |
| Max. flow | 100 l/min |
Other properties
| Connection diagram | ISO 4401-05-04-0-05 |
|---|---|
| ECLASS_13_Classification | 51-44-04-01 |
| Product family | Z1S10 |
| Spool symbol | A1 → A2 |
| Type of connection | Sandwich plate |
| Size | 10 |
| Type of actuation | with mechanical actuation |
| Number of ports | 5 |
| Number of switching positions | 2 |
| Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU,HFDR |
| Seals | FKM |
