Description
Physical size and weight
| Net weight | 2.02 kg |
|---|---|
| Operating pressure, max. | 350 bar |
| Max. flow | 50 l/min |
Other properties
| Connection diagram | ISO 4401-03-02-0-05 |
|---|---|
| Product family | WE6../E |
| ECLASS_13_Classification | 51-44-01-02 |
| Spool symbol | Symbol D46 |
| Type of connection | Subplate mounting |
| Size | 6 |
| Type of actuation | with solenoid actuation |
| Number of ports | 4 |
| Number of switching positions | 2 |
| Supply voltage | 24 VDC |
| Electrical connector | Connector, 4-pole, M12 x 1, coding A |
| Electrical connection description | Connector, 4-pole, M12 x 1 according to EN 61076-2-101, with LED and suppressor diode, pin assignment according to DESINA |
| Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
| Seals | NBR |
