Description
Physical size and weight
| Net weight | 7.28 kg |
|---|---|
| Operating pressure, max. | 315 bar |
| Max. flow | 100 l/min |
Other properties
| Connection diagram | ISO 6263-07-05-*-13 |
|---|---|
| ECLASS_13_Classification | 51-44-03-03 |
| Product family | 2FRM10,16 |
| Spool symbol | A → B, B → A |
| Type of connection | Subplate mounting |
| Size | 16 |
| Type of actuation | with mechanical actuation |
| Number of ports | 2 |
| Number of switching positions | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
| Seals | NBR |
