Description
Physical size and weight
| Net weight | 6.72 kg |
|---|---|
| Operating pressure, max. | 315 bar |
| Max. flow | 300 l/min |
Other properties
| Connection diagram | ISO 4401-07-07-0-05 |
|---|---|
| ECLASS_13_Classification | 51-44-04-01 |
| Product family | Z2S16 |
| Spool symbol | B1 → B2 |
| Type of connection | Sandwich plate |
| Size | 16 |
| Type of actuation | with mechanical actuation |
| Number of ports | 4 |
| Number of switching positions | 2 |
| Electrical connection description | 0 |
| Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
| Seals | NBR |
