Description
Features
- Suitable for controlling valve types 4WRA
- Built-up in the form of a board in the Euro-format 100 x 160 mm and is suitable for mounting into a rack
- Inversion of the internal command value signal via 24V input or by means of jumpers
- Selecting the ramp time via quadrantal recognition (24V input) or ramp time call-ups (24V input)
- With one ramp time
- Built-up in the form of a board in the Euro-format 100 x 160 mm and is suitable for mounting into a rack
- With one ramp time
- Polarity protection for the supply voltage, power supply with DC/DC convertor without a raised zero point
- Enable input, "ramp on/off" input, output signal "operational"
- Component series 2X
- Characteristic curve correction by separately adjustable jump heights and maximum values
- Switching over the ramp time range via jumpers
Tech Specifications
Type:
Analog
Series:
VT-VSPA2
Process Connection:
48 Pin Blade Connector, DIN 41612, Form F
Current Rating:
< 2A
Current Output:
2mA Signal, 0 - 2.5A Short-Circuit-Proof Stage
Voltage Rating:
24VDC
Power Rating:
< 50VA
Frequency Rating:
370 Hz Clock
Temperature Rating:
0 to 50 deg C
Dimensions:
182 mm Depth x 20 mm Width x 128.4 mm Height
Weight:
0.17kg
