KFD2-USC-1.D Pepperl+Fuchs Signal Converter with Trip Value
  1. KFD2-USC-1.D Pepperl+Fuchs Signal Converter with Trip Value

KFD2-USC-1.D Pepperl+Fuchs Signal Converter with Trip Value

Product Item:KFD2-USC-1.D

KFD2-USC-1D
Send Inquiry Live chat PDF

Description

General specifications
Signal type Analog input
Supply
Connection terminals 14+, 15- or Power Rail
Rated voltage 20 ... 30 V DC
Rated current ≤ 80 mA DC
Power consumption ≤ 1.6 W
Input
Connection side field side
Connection terminals 1+, 3- : mV, V ; terminals 2+, 3- : mA
Input resistance voltage: 1 MΩ , current: max. 100 Ω
Limit 30 V
Current 0 ... 20 mA
Voltage 0 ... 10 V / 0 ... 60 mV
Resolution 15 Bit
Output
Connection side control side
Connection output I: terminals 10, 11, 12
output II: terminals 7-, 8+, 9-
Output I signal, relay
Contact loading 250 V AC/2 A/cos φ 0.7; 40 V DC/2 A
Mechanical life 2 x 107 switching cycles
Energized/De-energized delay approx. 10 ms / approx. 10 ms
Output II analog
Load current: max. 550 Ω , voltage: min. 1 kΩ
Analog voltage output 0/1 ... 5 V , 0/2 ... 10 V
Analog current output 0/4 ... 20 mA
Transfer characteristics
Deviation 0.1 % of full-scale value
Resolution/accuracy current: 1 µA/20 µA
voltage: 0.5 mV/10 mV
mV: 3 µV/60 µV
Influence of ambient temperature 0.003 %/K (30 ppm)
Reaction time ≥ 150 ms/≤ 300 ms
Galvanic isolation
Input/Output reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Input/power supply reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Output/power supply reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff
Indicators/settings
Display elements display
Control elements Control panel
Configuration via operating buttons
Labeling space for labeling at the front
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)
Low voltage
Directive 2014/35/EU EN 61010-1:2010
Conformity
Electromagnetic compatibility NE 21
Degree of protection IEC 60529
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Mechanical specifications
Degree of protection IP20
Connection screw terminals
Mass 150 g
Dimensions 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) (W x H x D) , housing type B2
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001
General information
Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.

Classifications

System Classcode
ECLASS 11.0 27210107
ECLASS 10.0.1 27210107
ECLASS 9.0 27210107
ECLASS 8.0 27210107
ECLASS 5.1 27210107
ETIM 8.0 EC002475
ETIM 7.0 EC002475
ETIM 6.0 EC002475
ETIM 5.0 EC001485
UNSPSC 12.1 32101514
