KFD2-STC5-EX1 P+F SMART Transmitter Power Supply
- Product Item: KFD2-STC5-EX1
Description
- Manufacturer : Pepperl+Fuchs
- Product No. : KFD2-STC5-EX1
- Product type : SMART Transmitter Power Supply
- Signal type : Analog input
- Safety Integrity Level (SIL) : SIL 2
-
Supply Connection : Power Rail or terminals 14+, 15-
- Rated voltage Ur : 18 ... 30 V DC
- Power dissipation : = 1 W at maximum load
- Power consumption : = 1.6 W at maximum load
- Input Connection : field side, terminals 1+, 2-, 3
- Input signal : 0/4 ... 20 mA
- Output Connection : control side, terminals 7+, 8-, 9- (sink), terminals 7-, 8+, 9+ (source)
- Transfer Deviation at 20 °C (68 °F), 0/4 ... 20 mA = 10 µA incl. calibration, linearity, hysteresis, loads and fluctuations of supply voltage
- Ambient temperature : -20 ... 60 °C (-4 ... 140 °F)
- Degree of protection : IP20
- Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001
- Dimensions : 2 x 12.4 x 11.5 cm (0.8 x 4.9 x 4.5 inch) , housing type B2
- Weight : 0.15 Kg
- Shipping weight : 1 Kg
