Description
Features
- Suitable for controlling valve types 4WRA
- Built-up in the form of a board in the Euro-format 100 x 160 mm and is suitable for mounting into a rack
- Inverting the internal command value signal via the 24 V input or jumper
- Selecting the ramp time via quadrantal recognition (24V input) or ramp time call-ups (24V input)
- Switching over the ramp time range via jumpers
- Characteristic curve correction by separately adjustable jump heights and maximum values
- Component series 2X
- Enable input, "ramp on/off" input, output signal "operational"
- Polarity protection for the supply voltage, power supply with DC/DC convertor without a raised zero point
- With five ramp time
- With five ramp time
- Built-up in the form of a board in the Euro-format 100 x 160 mm and is suitable for mounting into a rack
Tech Specifications
| Type: | Analog |
| Series: | VT-VSPA2 |
| Process Connection: | 48 Pin Blade Connector, DIN 41612, Form F |
| Current Rating: | < 2A |
| Current Output: | 2mA Signal, 0 - 2.5A Short-Circuit-Proof Stage |
| Voltage Rating: | 24VDC |
| Power Rating: | < 50VA |
| Frequency Rating: | 370 Hz Clock |
| Temperature Rating: | 0 to 50 deg C |
| Dimensions: | 182 mm Depth x 20 mm Width x 128.4 mm Height |
| Weight: | 0.17kg |
