| General specifications | ||
|---|---|---|
| Signal type | Digital Input | |
| Supply | ||
| Connection | Power Rail or terminals 23+, 24- | |
| Rated voltage | 20 ... 30 V DC | |
| Rated current | approx. 100 mA | |
| Power consumption | 1.8 W | |
| Input | ||
| Connection side | field side | |
| Connection | Input I: terminals 1+, 3- ; input II: terminals 13+, 14- | |
| Input I | acc. to EN 60947-5-6 (NAMUR), see manual for electrical data | |
| Open circuit voltage/short-circuit current | 8.2 V / 10 mA | |
| Switching point/switching hysteresis | 1.2 ... 2.1 mA / approx. 0.2 mA | |
| Pulse duration | min. 75 µs / 1 ms see instruction manuals; the maximum input frequency has to be observed. | |
| Input frequency | 0 ... 80 Hz , pulse divider 0 ... 1 kHz | |
| Line fault detection | breakage I ≤ 0.15 mA; short-circuit I > 6.5 mA | |
| Input II | reset | |
| Active/Passive | I > 4 mA/I < 1.5 mA | |
| Open circuit voltage/short-circuit current | 18 V / 5 mA | |
| Pulse duration | min. 10 ms | |
| Output | ||
| Connection side | control side | |
| Connection | output I: terminals 10, 11, 12 ; output II: terminals 19+, 20- | |
| Output I | signal , Relay output | |
| Contact loading | 253 V AC/ 2 A / cos φ ≥ 0.7 ; 40 V DC/ 2 A | |
| Mechanical life | 5 x 107 switching cycles | |
| Energized/De-energized delay | approx. 20 ms / approx. 20 ms | |
| Output II | signal , electronic unit, isolated | |
| Contact loading | 40 V / 50 mA | |
| Energized/De-energized delay | after rising input flank 3 ms ; after falling input flank 2 ms | |
| Signal level |
1-signal: (L+) -2.5 V (50 mA, short-circuit/overload proof) 0-signal: blocked output (off-state current ≤ 10 µA) |
|
| Transfer characteristics | ||
| Input I | ||
| Resolution | < 0.1 % of the set value, min. 10 ms | |
| Accuracy | 2 ms | |
| Influence of ambient temperature | 0.003 %/K (50 ppm) | |
| Galvanic isolation | ||
| Input I/other circuits | reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff | |
| Output I/power supply and reset | reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff | |
| Output I, II against eachother | reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff | |
| Output II/power supply and collective error | basic insulation according to IEC/EN 61010-1, rated insulation voltage 50 Veff | |
| Output II/reset | basic insulation according to IEC/EN 61010-1, rated insulation voltage 50 Veff | |
| Reset/power supply and collective error | functional insulation acc. to IEC 62103, rated insulation voltage 50 Veff | |
| Indicators/settings | ||
| Display elements | LEDs , display | |
| Control elements | Control panel | |
| Configuration | via operating buttons | |
| Labeling | space for labeling at the front | |
| Directive conformity | ||
| Electromagnetic compatibility | ||
| Directive 2014/30/EU | EN 61326-1:2013 (industrial locations) | |
| Low voltage | ||
| Directive 2014/35/EU | EN 61010-1:2010 | |
| Conformity | ||
| Electromagnetic compatibility | NE 21:2006 | |
| Degree of protection | IEC 60529:2001 | |
| Ambient conditions | ||
| Ambient temperature | -20 ... 60 °C (-4 ... 140 °F) | |
| Mechanical specifications | ||
| Degree of protection | IP20 | |
| Connection | screw terminals | |
| Mass | approx. 300 g | |
| Dimensions | 40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch) (W x H x D) , housing type C2 | |
| Mounting | on 35 mm DIN mounting rail acc. to EN 60715:2001 | |
| Data for application in connection with hazardous areas | ||
| EU-type examination certificate | TÜV 99 ATEX 1408 | |
| Marking |
II (1)G [Ex ia Ga] IIC II (1)D [Ex ia Da] IIIC I (M1) [Ex ia Ma] I
|
|
| Supply | ||
| Maximum safe voltage | 40 V DC (Attention! The rated voltage can be lower.) | |
| Input I | terminals 1+, 3-: Ex ia | |
|
Voltage |
10.1 V | |
|
Current |
13.5 mA | |
|
Power |
34 mW (linear characteristic) | |
| Input II | terminals 13+, 14- non-intrinsically safe | |
|
Maximum safe voltage |
40 V (Attention! The rated voltage can be lower.) | |
| Output I | terminals 10, 11, 12 non-intrinsically safe | |
| Contact loading |
253 V AC/2 A/cos φ > 0.7; 40 V DC/2 A resistive load |
|
| Maximum safe voltage | 253 V (Attention! The rated voltage can be lower.) | |
| Output II | terminals 19+, 20- non-intrinsically safe | |
| Maximum safe voltage | 40 V (Attention! The rated voltage can be lower.) | |
| Certificate | TÜV 02 ATEX 1885 X | |
| Marking |
II 3G Ex nA nC IIC T4 Gc
|
|
| Output I | ||
| Contact loading | 50 V AC/2 A/cos φ > 0.7; 40 V DC/2 A resistive load | |
| Galvanic isolation | ||
| Input I/other circuits | safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V | |
| Directive conformity | ||
| Directive 2014/34/EU | EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 60079-15:2010 | |
| International approvals | ||
| FM approval | ||
| Control drawing | 16-538FM-12 | |
| UL approval | E223772 | |
| IECEx approval | ||
| IECEx certificate |
IECEx TUN 03.0000 IECEx TSA 18.0007X |
|
| IECEx marking |
[Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I Ex ec nC IIC T4 Gc |
|
| General information | ||
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. | |
| System | Classcode |
|---|---|
| ECLASS 11.0 | 27210121 |
| ECLASS 10.0.1 | 27210121 |
| ECLASS 9.0 | 27210121 |
| ECLASS 8.0 | 27210121 |
| ECLASS 5.1 | 27210121 |
| ETIM 8.0 | EC001485 |
| ETIM 7.0 | EC001485 |
| ETIM 6.0 | EC001485 |
| ETIM 5.0 | EC001485 |
| UNSPSC 12.1 | 32101514 |
